RIDGE FIRE COMPANY

Tool Mounting by GLICK

Graphics by GLICK

Year/Make/Model: 2020 Pierce® Freightliner M2-106 4X4

Type of truck: Pumper

Designation: 62-2

Engine: Cummins® L9 350 hp Engine with C-Brake

Transmission: Allison® 3000 EVS automatic 5-Speed with Aggressive Downshift



Pump: Waterous CXC20 1,000 GPM, Single Stage, Transfer Case Driven

Water tank size: 500-gallon Poly Tank

Foam cell:  30 Gallon Class-A Foam Cell

Foam system:  Husky®3 Single Agent, with Hercules CAFS system

Generator:  Onan 7.5KW Diesel Generator



Overall Height: 133.00” (11’ 1”)

Overall Length: 336.30” (28’ .30”)

Wheelbase: 205.00”

Seating: Seating for 4



Additional details:

• Four door cab
• Pierce® back-up camera
• Zico Quick-Lift Ladder Rack
• One (1) 5” discharge
• Three (3) Rear Discharges
• Two (2) Booster Reels with 150’ of 1.00” hose
• (2) tow bars with hitch receiver
• All plumbing Stainless Steel
• DOT lighting to be LED
• Whelen LED warning light package
• Federal Q2B Siren and Whelen Electronic Siren
• Cord Reel with 200’ of 10/3
• HiViz Scene Lighting package
• Alcoa Aluminum Wheels
• Air Conditioning
• Floor Console
• Unit will be painted Department Colors White over Red
• Lettering and Striping by Danz
• Custom Tool Mounting by Glick Fire Equipment
