CONSHOHOCKEN FIRE DEPT

Year/Make/Model: 2019 Pierce® Enforcer™

Type of truck: PUC 107’ Ascendant Heavy-duty ladder

Designation: Quint 35

Engine: Cummins L9, 450 hp Engine

Transmission: Allison 3000EVS



Water tank size: 500-gallon water tank

Pump: Pierce, 1500 GPM, Single Stage, PUC

Foam cell:  20-gallon Class A, Not Reduce Water, PUC

Generator:  Harrison 6kW MCR Hydraulic



Overall Height: 141.00” (11’ 9”)

Overall Length: 469.50” (41’ 4.50”)

Wheelbase: 234.00″

Seating Capacity: 6



Additional details:

• High Flow 1500 GPM Waterway,
• Quick-Lock Waterway Locking System
• Akron 3486 StreamMaster II Monitor
• Side Roll and Frontal Impact Protection
• TAK-4 front suspension
• 22-inch extended bumper with center hose tray
• (1) 3.00″ Tank to Pump Valve
• (2) 1.50″ Low Mount Crosslays
• (1) 2.50″ Crosslay
• Alum 4-Way Slide-Out Platform, 500 lb Capacity, Full Width
• Vehicle Information Center, 7″ Color Display, Touchscreen, MUX
• Pierce® camera system
• HiViz and Pioneer emergency lighting
• Chrome tow hooks
• Air conditioning
• Gortite® roll-up doors

(2) Grover Air Horns In Bumper

Federal Q2B® Siren
